SKD R

The SKD R is a circular ceiling swirl diffuser equipped with radially arranged air deflectors for supply or extract air.

Its design ensures high air flow capacity while maintaining low sound power levels. The rotatable air deflectors allow flexible adjustment of the distribution pattern, which can be set via an electric motor or thermal slat.

The adjustable air deflectors are mounted in slat holders, allowing the distribution pattern to be adjusted as needed. By individually adjusting the air deflectors, the distribution pattern can be adapted to the room’s architectural features, enabling air flow to effectively navigate around nearby elements such as columns, cabinets, or wall protrusions.

Diffuser face

• Made of galvanised steel.
• Standard colour:
  • RAL 9003, signal white, gloss 70
• Alternative standard colours:
  • RAL 9010, pure white, gloss 70
  • RAL 9006, white aluminium, gloss 70
  • RAL 9005, jet black, gloss 70
  • RAL 7035, light grey, gloss 70

Air deflectors

• Made of extruded aluminium.
• Standard colour:
  • RAL 9005, jet black

Slat holder

• Made of stainless steel.
• Standard colour:
  • RAL 9005, jet black

• Other colours available on request.
• Available in stainless steel or aluminium on request.
• Available in a version certified according to VDI 6022.

The diffuser face is mounted using a central screw fastening (size 800 with additional screws in the edge region).

SKD R circular ceiling swirl diffuser with adjustable air deflectors with the following features:

• Diffuser face with radially inserted air deflectors.
• Available in a supply air or extract air variant.
• Diffuser face made of galvanised steel, standard colour white (RAL 9003).
• Air deflectors made of extruded aluminium profiles, standard colour black.
• Slat holders made of stainless steel, standard colour black.
